A-House

Pre - Fabricated Metal House 20' x 20'

pre-fabricated house

1 / 5
Pre - Fabricated A-House
2 / 5
Pre - Fabricated A-House
3 / 5
Pre - Fabricated A-House
4 / 5
Pre - Fabricated A-House
5 / 5
Pre - Fabricated A-House


BLUEPRINTS FOR SALE

About this Plan

Instant Downloads available:

https://www.etsy.com/shop/ArchitectChin

Description of Digital Download:

Digital 20 PDF Blueprints of Prefab Modern V-House, Plan, Elevations, Section, Sectional Details, Roof Frame Plan, and Materials are described in the drawings. Framing details of Roof, internal and external Walls. Framing details of Roof, internal and external Walls, Toilet details, Floor Details. PDF Format, A4 size.

Diagonal Watermarks will not be visible in the downloaded files you purchase.

Advantages of this Design:

All materials are available off-the-shelf from hardware stores. Easy to prefab and install. Minimal in-situ works, most work can be prefabricated in a factory. Only the concrete footings need to be cast onsite. The rest of the materials can be prefabricated and delivered to site pre-built and pre-finished. All metals frames can be pre-welded in factory and will fit into the back of a lorry.

We designed this house for Time, Labor and Costs savings. The site footing casting can be done by one team of workers while the materials are being pre-built in the factory by another team of workers, thus saving time. This way you don’t have to wait until your footings are completed to start the fabricating walls and floors.  Building in a factory has many advantages such as quality and precision control. Minimal wastage. And you can work under any weather conditions. Your house can be built by 2 separate team of workers working simultaneously, saving time and costs.

Lightweight materials, designed for hand carry by 2 persons.

It can be installed on flat land or hill slopes.

Description of House:

One unit includes a toilet, bedroom, and balcony.

Size of house is 10' x 20' = 200 square feet per module.

You can put a few units together to get bigger units of 400 SF, 600 SF, 800 SF, 1,000 SF, and so on.

You can extend the length of the house to any suitable length. (Width = 20')

Metal Frame, dry floor and wall construction (cement fibre board, timber board, glass, plywood, etc.), Metal roofing, Concrete Footings, Metal stumps

Costs of materials are estimated to be around USD15, 000.

House Feature:

A - House (20’ x 20’) 200 Sq. Feet on the flat ground.
V - House (20’ x 20’) 200 Sq. Feet on hill slope.
•      20’ x 20’
•      Balcony,  Bathroom, Bedroom,
       Living / Dining,
       Pantry
•      Cool Design.
•      Fast installation.
•      Excellent for slope or flat land; no hill cutting is necessary.
•      Superb quality control.
•      Saves on time, labour & supervision.
•      Strong, weather proof & robust.
•      Fits together like Lego.
•      Ideal for houses, resorts chalets, foyers, restaurants, offices, etc.

PREFABRICATED A-HOUSE


•    Cool Design.
•    Fast installation.
•    Excellent for slope or flat land; no hill
•    Cutting is necessary.
•    Superb quality control.
•    Saves on time, labour & supervision.
•    We provide Design & Build package deal.
•    Strong, weather proof & robust
•    Fits together like Lego.
•    Houses, chalets, foyers, restaurants, offices, etc.
•    Sanitary fittings, mosquito nets, lights,
•    Fans are included.
•    Ships worldwide.
•    Contact us:
•    Telephone No.: +6088-268205
•    Fax No.: +6088-268207
•    Email: chin178@gmail.com





BUY DIGITAL PLANS
RM 2, 999.00




BUY DIGITAL PLANS
RM 2, 399.99

Basic Information

Designer

Chin Architect

Name Of Plan

V-House or A-House

Number of Bedrooms / Sleeping Areas

1

Square Footage

200 sf

Approximate Weight

?

Approximate Cost to Build DIY

RM?

Approximate Cost to Have Built

RM?

Select and Purchase Your Plan


·         PDF (Price On Application)

•    PDF (Price On Application)

    - Delivered via email in digital format,
      the fastest way to receive your plan.
      SAVE on shipping costs and processing
      delays!

•     5 Copy A1 size Construction Set (Price On Application)

    - Send by courier service with free shipping within Malaysia.
      International shipping charges may apply.

House Feature:

A - House (10’ x 20’) 200 Sq. Feet on the flat ground.
V - House (10’ x 20’) 200 Sq. Feet on hill slope.

•    10’ x 20’
•    Balcony
•    Bathroom
•    Bedroom
•    Cool Design
•    Fast installation
•    Excellent for slope or flat land; no hill cutting is necessary.
•    Superb quality control.
•    Saves on time, labour & supervision.
•    Strong, weather proof & robust.
•    Fits together like Lego.
•    Ideal for

What’s in the Plan?

1. Floor Plans

Floor plans show the layout of the house. Rooms and interior spaces are carefully dimension, doors and windows located, and keys are given for cross-section details provided elsewhere in the plans.

2. Elevations

In addition to the front exterior, your blueprint set may include drawings of the rear and sides of your house. These drawings give notes on exterior materials and finishes. Particular attention is given to detail service panel or other finish items that make your home unique.

3. Sections

Large-scale views show sections or cutaways of the foundation, interior walls, exterior walls, floors and roof details. Additional cross-sections may show important changes in floor, ceiling, or roof heights.

These sections show exactly how the various parts of the house fit together and are extremely valuable during construction. Additional sheets may include enlarged wall, floor, and roof construction details.

4. Panel Details

Details show main metal framing panels, roof frame panels, floor panels, wall panels for pre-fabrications. Installation steps that are easy to follow.

5. Specifications

Details of materials, size, selected brands for costing and orderings.
